10Gbps 24AWG Direct Attach Copper Cable 7m QSFP DAC Cable

  • 1
  • 2
  • 3

Brand Name : UNIFIBER-OEM

Model Number : 40G QSFP+ DAC Cable

Certification : ROHS

Place of Origin : CHINA

MOQ : 10pcs

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 500pcs/day

Delivery Time : 3~5 business days

Packaging Details : Carton box

Product : 40G QSFP DAC Cable

Wire AWG : 24/28/30AWG

Connector : QSFP+ to 4*SFP+

Data Rate : 10Gbps

Transmission distance : up to 7m

Application : Data Center

Contact Now

High Speed 40G QSFP+ to 4×10G SFP+ Direct Attach Cable copper cable assemblies are a low cost alternative for short reach 4X applications. They are designed to be fully compatible in form factor and optical/electrical connections according to the QSFP Multi-Source Agreement.QSFP+ connectors provide four channels of data in one pluggable interface. Each channel is capable of transferring data at 10Gbps and supports a total of aggregate 40Gbps as specified for QSFP+. These interconnects have three times the density of SFP+ interconnects (MSA) and have been designed to meet the harshest external operating conditions including temperature, humidity and EMI interference.

Application

10G/40G Ethernet
InfiniBand, Fiber Channel 4G/8G/10G
Sonet Multiplatform support
High Performance Computing Clusters
High End Servers
Metro Network Switch/Cross Connect

Features

* 4-Channel Full Passive Copper Cable Transceiver
* QSFP+ conforms to the Small Form Factor SFF-8436and SFF-8431
* Support for multi-gigabit data rates up to 10.5Gbps
* Data rates backward compatible to 1Gbps
* Maximum aggregate data rate: 40 Gbps (4 x 10Gbps)
* Hot-DensityQSFP 38-PIN footprint
* I/O Connector designed for high speed differential signal applications
* Improved Pluggable Form Factor(IPF) compliant for enhanced EMI/EMC performance
* Compatible with industry standard SFP cages +Switches
* Temperature Range: 0~ 70 °C
* RoHS-6 Compliant

Compliant

Compliant with electrical standards IEEE 802.3ba
Compliant with mechanical standard SFF-8436 and SFF-8431
Compliant with EEPROM standard SFF-8472
RoHS Compliant
Series Product Description

40G DAC

QSFP+ to 4SFP+

 QSFP+ to 4SFP+, 40Gb/s, DAC, 0.5M, AWG30
QSFP+ to 4SFP+, 40Gb/s, DAC, 1M, AWG30
QSFP+ to 4SFP+, 40Gb/s, DAC, 2M, AWG30
QSFP+ to 4SFP+, 40Gb/s, DAC, 3M, AWG30
QSFP+ to 4SFP+, 40Gb/s, DAC, 4M, AWG26
QSFP+ to 4SFP+, 40Gb/s, DAC, 5M, AWG26

10Gbps 24AWG Direct Attach Copper Cable 7m QSFP DAC Cable10Gbps 24AWG Direct Attach Copper Cable 7m QSFP DAC Cable
